Introducing the high-performance Vacuum Dryers from Changzhou General Equipment Technology Co., Ltd. Our range includes Square vacuum dryer, Circular vacuum dryer, Conical Vacuum Dryer, and more, catering to the diverse needs of industries such as pharmaceutical, chemical, foodstuff, and electronic industries. Our Vacuum Dryers operate under vacuum conditions, resulting in decreased boiling points of raw materials and higher evaporation efficiency. This innovative design allows for a more efficient heat transfer, saving on conducting area. The heat source for evaporation can be low pressure steam or surplus heat steam, reducing heat loss significantly. One of the key advantages of our Vacuum Dryers is the ability to carry out disinfection treatment before drying, ensuring no impurity material is mixed during the process. This adherence to GMP standards makes our dryers ideal for sensitive raw materials that can decompose or deteriorate at high temperatures. The Square, Circular, and Conical Vacuum Dryers from Changzhou General Equipment Technology Co., Ltd. are designed to maintain the shape of raw materials during drying, preserving their integrity. With multiple layers of baking shelves and adjustable intervals, our dryers offer flexibility and efficiency in drying processes. Choose Changzhou General Equipment Technology Co., Ltd. for reliable and high-quality Vacuum Dryers that meet the stringent requirements of various industries. Trust in our expertise and innovation to elevate your drying processes to new levels of efficiency and productivity.

It is well known that vacuum drying is to put raw material under the state of vacuum for heating and drying. If use vacuum to pump air and humidity out, the dry speed will be faster.Note: if use condenser, the solvent in raw material can be recovered. If the solvent is water, condenser might be canceled and the investment and every could be saved.

Feature：

• Under the condition of vacuum, the boiling point of raw material will decrease and make the evaporation efficiency higher. Therefore for a certain amount of heat transfer, the conducting area of dryer can be saved.• The heat source for evaporation may be low pressure steam or surplus heat steam.• The heat loss is less.• Before drying, the treatment of disinfection may be carried out. During the period of drying, there is no impurity material mixed. It is in conformity with the requirement of GMP standard.• It belongs to static dryer. So the shape of raw material to be dried should not be destroyed.



Application:

---

It is suitable for drying heat sensitive raw materials that can decompose or polymerize or deteriorate at high temperature. It is widely used in pharmaceutical, chemical, foodstuff and electronic industries.



SPEC

---

Specification Item	YZG-600	YZG-800	YZG-1000	YZG-1400	FZG-15
Inside Size Of Chamber (mm)	Φ600×976	Φ800×1274	Φ1000×1572	Φ1400×2054	1500×1220×1400
Outside Size Of Chamber (mm)	1153×810×1020	1700×1045×1335	1740×1226×1358	2386×1657×1800	2060×1513×1924
Layers Of Baking Shelf	4	4	6	8	8
Interval Of Baking Shelf	81	82	102	102	122
Size Of Baking Disk	310×600×45	460×640×45	460×640×45	460×640×45	×460×640×45
Numbers Of Baking Disk	4	8	12	32	32
Permitted Level Inside Chamber Without Load (Mpa)	≤0.784	≤0.784	≤0.784	≤0.784	≤0.784
Temperature Inside Chamber (℃)	-0.1
When Vacuum is 30 torr And The Heating Temperature is 110 ℃, Vaporized Rate Of Water	7.2
Type And Power Of Vacuum Pump Without Condensate (kw)	2X15A 2kw	2X30A 23w	2X30A 3kw	2X70A 5.5kw	2X70A 5.5kw
Type And Power Of Vacuum Pump Without Condensate (kw)	SZ-0.5 1.5kw	SZ-1 2.2kw	SZ-1 2.2kw	SZ-2 4kw	SZ-2 4kw
Weight Of Drying Chamber (kg)	250	600	800	1400	2100



Detail

---

Under the condition of vacuum, the boiling point of raw material decreases significantly, resulting in higher evaporation efficiency for your SP production line. Our vacuum dryers from Changzhou General Equipment Technology Co., Ltd. are manufactured with precision and quality to meet the demands of modern industrial processes. With advanced technology and innovative design, our products ensure optimal performance and reliability for your production needs. Trust GETC for cutting-edge solutions in vacuum drying technology.
