Welcome to Changzhou General Equipment Technology Co., Ltd., where we offer a wide range of high-quality horizontal oriented jet mill, mixer, plough mixer, ribbon blender, ribbon mixer, and pin mill for sale. Our innovative designs and advanced technology make our equipment highly efficient and easy to operate. When it comes to dispersing and milling applications in industries such as coating, paint, printing ink, and agricultural chemicals, our products are the perfect solution. Our horizontal mixers, plough mixers, and ribbon blenders are designed for viscosities below 20,000 cps and can handle large amounts of solid-liquid suspensions with high viscosity. We take pride in the superior safety performance of our imported container type double mechanical seals, ensuring the protection of your materials during the milling process. The pins and chambers of our equipment are made of highly wear-resistant alloy, extending the service life of the machines. With our cooling systems equipped on the shell, end face, and main shaft, the material temperature can be held within 45℃, providing a stable and efficient milling process. The separating grid, made of special highly wear-resistant material, can be adjusted to accommodate different grinding bead sizes and prevent blockages. Experience the advantages of Changzhou General Equipment Technology Co., Ltd. in providing high-quality, efficient, and reliable horizontal mixers, plough mixers, ribbon blenders, ribbon mixers, and pin mills for all your dispersing and milling needs. Choose us for unmatched performance and exceptional results in your production processes.

The agitator shaft activates the grinding media with high intensity through the whole grinding chamber. The highly efficient devices are suitable for product separation and grinding media, which ensures that the mill also has the capability of operating high viscous materials.

Introduction:

The agitator shaft activates the grinding media with high intensity through the whole grinding chamber. The highly efficient devices are suitable for product separation and grinding media, which ensures that the mill also has the capability of operating high viscous materials.



Feature:

• High efficiency, strong operability.
• Suitable for viscosities below 20,000 cps.
• Suitable for large amount of solid-liquid suspension of high viscosity.
• Imported container type double mechanical seal, superior in safety performance to other pin sand mill. Pins and chamber are made of highly wear-resistant alloy to extend service life.
• No discoloring or pollution to the raw materials.
• All of the shell, end face and main shaft are equipped with cooling system with good performance. The material temperature can be held within 45℃(through chilling water of 10℃).
• Separating grid: of special highly wear-resistant material. Space between the grids can be adjusted according to the grinding bead sizes. A protector is available to prevent the blocking of the beads.

Application:

Dispersing and milling in the field of coating, paint, printing ink, agricultural chemical, etc.



Specification：

Model	Volume (L)	Dimension (L×W×H) (mm)	Motor (kw)	Feeding Speed (L/min)	Adjustable Volume (L)
WMB-10	10	1720×850×1680	18.5	0-17	9-11
WMB-20	20	1775×880×1715	22	0-17	20-22.5
WMB-30	30	1990×1000×1680	30	0-17	30-33.5



When it comes to processing lithium nickel cobalt oxide materials, our Jet Mill and Mixer stands out for its superior efficiency and precision. The agitator shaft activates the grinding media with high intensity throughout the grinding chamber, ensuring a uniform and thorough crushing and pulverizing process. With a horizontal orientation for easy operation and maintenance, this machine is a reliable and cost-effective solution for your material processing requirements. Trust GETC for high quality equipment that delivers exceptional results every time.
