Introducing the Mechanical Disc Pulverizer from Changzhou General Equipment Technology Co., Ltd. This Disc Pulverizer, also known as a Mill or Lab mill, is designed for high performance crushing and grinding of various materials. With its convenient grinding gap adjustment in 0.05 mm steps and digital gap display, the Disc Pulverizer allows for precise control over the grind size. The TFT display with robust membrane keyboard makes operation simple and user-friendly. Featuring a large, removable plastic funnel with smooth inner surfaces, the Disc Pulverizer is easy to clean and ensures optimal material feeding. The zero point adjustment allows for wear compensation of the grinding disc, while the smooth inner surfaces of the grinding chamber enable residue-free cleaning. The additional labyrinth sealing seals the grinding chamber, providing a dustproof environment for operation. Ideal for applications such as powder milling, battery material grinding, and pharmaceutical processing, the Disc Pulverizer offers excellent crushing performance. The progressively arranged grinding disc meshing ensures thorough comminution of the sample, producing consistent and reliable results. The centrifugal force moves the sample to the outer regions of the grinding discs for fine comminution, while the adjustable gap width allows for customization of the grind size. Experience the advantages of Changzhou General Equipment Technology Co., Ltd. with this high-quality Mechanical Disc Pulverizer. Trust in our expertise and innovation for all your grinding and pulverizing needs.

It is the new comfort model for fine grinding of medium-hard, hard and brittle materials down to 0.05 mm. This model is based on the well-proven DM 200 but offers improved safety features due to the automatic locking of the collecting vessel and grinding chamber, as well as particularly convenient operation thanks to the motor-driven grinding gap adjustment with digital gap display. The clearly structured display shows all grinding parameters.

Brief Introduction：

---

It can be used under rough conditions in laboratories and pilot plants, as well as online for the quality control of raw materials. The powerful DM 400 requires only a few minutes to achieve the desired grind size.

The feed material enters the dustproof chamber from the filling hopper and is fed centrally between two vertical grinding discs. A moving grinding disc rotates against a fixed one and draws in the feed material. The necessary comminution effects are generated by pressure and frictional forces. The progressively arranged grinding disc meshing first subjects the sample to preliminary crushing; centrifugal force then moves it to the outer regions of the grinding discs where fine comminution takes place. The processed sample exits through the grinding gap and is collected in a receiver. The gap width between the grinding discs is incremental adjustable and can be motor-driven adjusted during operation in the range between 0.1 and 5 mm.



Features:

---

• Excellent crushing performance.• Convenient grinding gap adjustment in 0.05 mm steps – with digital gap display.• TFT display with robust membrane keyboard.• Large, removable plastic funnel with smooth inner surfaces for easy cleaning and optimum material feeding.• Wear compensation of grinding disc thanks to zero point adjustment.• Smooth inner surfaces of grinding chamber allow for easy and residue-free cleaning.• Additional labyrinth sealing seals the grinding chamber.• Easy change of grinding discs.• Optional version with polymer interior coating.

Application:

---

Bauxit, Cement Clinker, Chalk, Chamotte, Coal, Concrete, Construction Waste, Coke, Dental Ceramics, Dried Soil Samples, Drilling Cores, Electrotechnical Porcelain, Ferro Alloys, Glass.



SPEC:

---

Model	Capacity (kg/h)	Speed Of Axis (rpm)	Inlet Size (mm)	Target Size (mesh)	Motor (kw)
DCW-20	20-150	1000-4500	＜6	20-350	4
DCW-30	30-300	800-3800	＜10	20-350	5.5
DCW-40	40-800	600-3400	＜12	20-350	11
DCW-60	60-1200	400-2200	＜15	20-350	12



Detail

---

Looking to enhance the efficiency and accuracy of your lab or pilot plant operations? Look no further than our high performance air jet mill micronizer. With the ability to control particle sizes down to the micron level, this cutting-edge equipment is perfect for quality control of raw materials. Its robust design ensures reliable performance even under the toughest conditions, making it a valuable asset for any research or production facility. Trust GETC for innovative solutions that meet your specialized needs.
