Introducing the top-of-the-line Automatic Big Bag Packing Machine from Changzhou General Equipment Technology Co., Ltd. This packaging machine is specifically designed for powdery and granular material packing, making it ideal for various industries such as agriculture, chemical, and food. The unit is equipped with automatic bag-fetching, filling, conveying, and sealing functions, streamlining the packaging process. With features like automatic bag loading, weighing, filling, sealing, date printing, counting, and cargo anti-counterfeit measures, this machine offers unmatched convenience and efficiency. The machine's stable performance is enhanced by imported color-coded photoelectric sensors and high-quality module sensors, ensuring accurate positioning and stable measurement. The full PLC and HMI operation make controlling the machine more convenient. The machine is easy to operate and stable, thanks to the adoption of Siemens PLC and a 10-inch color touch screen in the control part. The pneumatic part utilizes Festo solenoids, oil-water separators, and cylinders, while the vacuum system features Festo solenoids, filters, and digital vacuum pressure switches. Safety is a top priority with magnetic switches and photoelectrical switches in every movement mechanism. The Automatic 25kgs big bag packaging machine unit is specially suitable for powdery materials, with a packaging range of 10-50kg and a maximum speed of 3-8 bags/min. Its high efficiency and advanced design make it suitable for various packaging requirements. Trust Changzhou General Equipment Technology Co., Ltd. for innovative and reliable packaging solutions. This packaging machine is developed for powdery & granular material packing applied in agriculture, chemical and food etc. industries. The unit is provided with the functions of automatic bag-fetching, automatic filling, automatic bag-conveying and sealing. It can be used for powder or granular materials production lines for the large-sized bags filling & packaging operations.

1. Introduction:

This packaging machine is developed for powdery & granular material packing applied in agriculture, chemical and food etc. industries. The unit is provided with the functions of automatic bag-fetching, automatic filling, automatic bag-conveying and sealing. It can be used for powder or granular materials production lines for the large-sized bags filling & packaging operations.The machine integrates the functions of automatic bag loading, weighing, filling, sealing, date printing, counting, cargo anti-counterfeit & anti-channeling in one;Machine performance is stable; Imported color-coded photoelectric: more accurate positioning; High -quality module sensor: more stable measurement, Full PLC & HMI operation: more convenient controlling.

2. Feature:

The machine is easy operated and stable because of adopting Siemens PLC and 10 inch color touch screen in control part.



Pneumatic part adopts Festo solenoid, oil- water separator, and cylinder.



Vacuum system adopts Festo solenoid, filter, and digital vacuum pressure switch.



The magnetic switch and photoelectrical switch are provided in every movement mechanism, which is safe and reliable.

3. Application:

Automatic 25kgs big bag packaging machine unit is specially suitable for powdery material, the packaging material is paper bag, PE bag, woven bag, the packing range is 10-50kg, the maximum speed can reach 3-8bags/min. High efficiency, advanced design suitable for various requirements.

4. Specification:

Packaging material:prefabricated woven bag (lined with PP/PE film), kraft paper bags.


Size of bag making:(700-1100mm)x(480-650mm) L*W

Measuring range: 25-50KG

Measurement accuracy: ±50G

Packaging speed: 3-8 bags/min (slight variation depending on the packaging material, bag size etc.)

Ambient temperature: -10°C~+45°C

Power: 380V 50HZ 1.5KW

Air Consumption: 0.5~0.7MPa

External dimensions: 4500x3200x4400mm (Can Adjust)

Weight: 2200kg

5. Detail:


Looking for a reliable and efficient powder packing solution? Look no further than our automatic powder packing machine, designed and manufactured by Changzhou General Equipment Technology Co., Ltd. This state-of-the-art machine is equipped with tungsten carbide crusher / pulverizer components, ensuring exceptional durability and performance. With its advanced technology and precision engineering, our machine guarantees accurate and consistent packaging, saving you time and resources in your production process. At GETC, we prioritize quality and innovation in all our products, and our automatic powder packing machine is no exception. Whether you're in the pharmaceutical, food, or chemical industry, our machine offers versatile packaging solutions to meet your specific needs. Trust in the expertise of Changzhou General Equipment Technology Co., Ltd. and experience the difference our high-quality equipment can make in your production line. Choose reliability, choose efficiency, choose GETC.
