Welcome to Changzhou General Equipment Technology Co., Ltd., where we offer a wide range of high-quality horizontal mixing and milling equipment for various industries. Our horizontal oriented jet mill, Horizontal mixer, Horizontal Plough Mixer, horizontal ribbon blender, horizontal ribbon mixer for sale, Horizontal Ribbon Mixer, mixer horizontal, horizontal dough mixer, Horizontal Vibration Fluid bed Dryer, and Mill are designed for optimal performance and efficiency in grinding and mixing processes. Our equipment features dual end surface mechanical sealing for reliability and durability, along with cooling liquid compatibility to reduce pollution. The machines are designed for easy operation with high production efficiency, ensuring that materials are ground to the required fineness in a short amount of time. With different models available, we can meet the specific requirements of our customers. Our machines boast low energy consumption ratios and high cost-effectiveness, making them a top choice among grinding machines. The specially designed grinding discs offer higher efficiency and lower electric consumption, resulting in a higher performance-cost ratio. The integrated on-spot control panel makes operation and cleaning a breeze. Additionally, our equipment is equipped with cooling jackets in the grinding chamber, allowing for efficient temperature control. The temperature monitor and control system ensures the quality of the finished products, with settable protection values for peace of mind. Trust in Changzhou General Equipment Technology Co., Ltd. for all your horizontal mixing and milling needs. Experience the difference in quality and performance with our top-of-the-line equipment.

The delivery pump circulates the materials in the tank and the materials in the grinding chamber. The discs drive the grinding medium inside the grinding chamber to do irregular movements in all direction to put the materials under
the. action of constant collision and friction. At same time, the materials are separated from the grinding medium by the sieve and keep circulating from the tank to the grinding chamber to obtain smaller particle size, narrower particle size range.

Brief Introduction:

---

The machine adopts the dual end surface mechanical sealing with reliability and durability, mated with the Cooling liquid compatible to the ground material in order to reduce the pollution of ground material. It makes the material into aggressiveness and give the strong grind so that the grains reaches the required fineness in short time.The machine is easily operated with reliability and high production efficiency. Depending to different requirements, the different models of machines can satisfy with customers.The type dispersing disk is functioned by the slot hole and multiplied profiles to produce the strong bump and friction among mediate ball bodies.Therefore, the material can be ground and dispersed in high efficiency.



Features:

---

• Low energy consumption ratio, High cost-effective
• With the belts to conveyor driving force from the motor of the main shaft. The grinding discs are specially designed to have higher effiency and lower electricconsumption. It is with higher performance-cost ratio among the grinding machines.
• The machine is with integrated on-spot control panel, easy to operate and clean.
• Grinding chamber is with cooling jackets. Input cooling water into the jacket when running to have good cooling result, normally the temperature increase will be within 10℃.
• The machine is with temperature monitor and control. With settable protection value to ensure the quality of the finished products.
• Full specification, can be customized
• Specifications ranges from 5L to 100L, which can be customized to be Ex-proof type.• Grinding chambers made of Polyurethane or Zirconium are in option to ensure its  anti-abrasiveness and alsoto prevent materials from metal pollution.


Application:

---

Dispersing and milling in the field of coating, paint, printing ink, agricultural chemical, etc.



SPEC:

---

Model	Volume (L)	Dimension (L×W×H) (mm)	Motor (kw)	Feeding Speed (rpm)	Capacity (kg/h)
WM-30	30	1650×800×1600	22	0-40	50-60
WM-50	50	2100×1050×1700	30	0-40	100-800
WM-60	60	2310×1150×1650	30	0-40	100-1000
WM-90	90	2500×1150×1700	37/45	0-40	120-1200
WM-100	100	2550×1180×1720	45	0-40	150-1350



Detail

---

The Ingersoll Rand Diaphragm Pump equipment offered by Changzhou General Equipment Technology Co., Ltd. features dual end surface mechanical sealing for enhanced reliability and durability. Our machines are designed with cooling liquid compatibility to reduce pollution of ground material, providing efficient and effective mixing and milling solutions. With a focus on high-quality construction and performance, our equipment is ideal for a wide range of industrial applications.
