The Universal Pulverizer offered by Changzhou General Equipment Technology Co., Ltd. is a versatile machine that utilizes high-speed revolving cutters to effectively crush and shear various materials. With a production capacity ranging from 60-800 kg/h, this pulverizer is perfect for applications in the chemical industry, medicine, foodstuff, spice production, and more. The machine is designed to meet GMP standards, ensuring that all materials remain free from contamination. With adjustable fineness settings and automatic powder collection, the Universal Pulverizer offers advanced crushing capabilities. Trust in the expertise of Changzhou General Equipment Technology Co., Ltd. to deliver high-quality pulverizers for your processing needs.

The universal mill is a compact, high-speed impact mill capable of fine size reduction with interchangeable element configurations. The mills have been developed to meet the specific requirements of the food, pharmaceutical, and chemical industries. Typical milled particle size range down to a D90 of 150mesh.



Introduction:

This multi-functional universal pulverizer  utilizes the relative movement between the moving-gear and fixture gear. The materials are pounded by dish, rubbing and materials are each other pounded. Thereby the materials are crushed. The materials that are already smashed through the function of revolve eccentricity power, enter into gathering bag automatically. The powders are filtered through dust arrester-box. The machine adopts GMP standard design, using the stainless steel materials all, having no powder to float in the production line. Now it already reaches international advanced level.



Features：

This machinery adopts wind-wheel type, high-speed revolving cutters to mill and shear the materials. This processing achieves excellent crushing effect and crushing energy and finished products are blown out from screen mesh. The fineness of the screen mesh is changeable by various screens.



Applications:

This machinery is mainly applicable for weak-electric substances and high temperature-resistant substances such as chemical industry, medicine (Chinese medicine and medicine herbs), foodstuff, spice, resin powder, etc.





Specification：

Type	DCW-20B	DCW-30B	DCW-40B
Production capacity (kg/h)	60-150	100-300	160-800
Main shaft speed (r/min)	5600	4500	3800
Size of input (mm)	≤6	≤10	≤12
Crushing size (mesh)	60-150	60-120	60-120
Crushing motor (kw)	4	5.5	7.5
Motor of absorbing dust (kw)	1.1	1.5	1.5
Overall dimensions L×W×H (mm)	1100×600×1650	1200×650×1650	1350×700×1700





Introducing the cutting-edge Pulverizing mill from GETC. Our innovative design utilizes the relative movement between the moving-gear and fixture gear to ensure superior performance. With a focus on versatility and durability, our pulverizer is the perfect solution for a wide range of applications. Trust GETC to provide you with a high-quality pulverizing mill that meets your needs and exceeds your expectations.
